Low-Power Wireless Sensor Networking - Mesh 2.4 GHz
ZigBee OEM RF Modules, Dev Kits, and Gateways
Low power and low cost, RFM ZigBee radio solutions are
ZigBee OEM Modules
perfect for home, commercial, and industrial applications,
operating from -40°C to +85°C.
Every ZigBee module from RFM comes with FCC, IC and
ETSI module certification. This means FCC type acceptance
testing is not required for devices into which the OEM RF
modules are integrated, saving you money and getting your
product to market faster.
Product No.
ZMN2405
ZMN2405HP
ZMN2405HPA
ZMN2430
ZMN2430A
ZMN2430HP
ZMN2430HPA
Frequency
2.4 GHz
2.4 GHz
2.4 GHz
2.4 GHz
2.4 GHz
2.4 GHz
2.4 GHz
Transmit Power
1 mW
10/100 mW
10/100 mW
1 mW
1 mW
10/100 mW
10/100 mW
Channels
16
15
15
16
16
15
15
Data Rate
250 Kbps
250 Kbps
250 Kbps
250 Kbps
250 Kbps
250 Kbps
250 Kbps
When ordering add the letter to the pa rt number to specify for Coordinator (-C), End Device (-E) or Router (-R)
OEM Modules
ZigBee Development Kits
A low-cost, low-power ZigBee module from RFM is ideal for
low data rate, wireless applications, including sensor
monitoring, building and home automation, and any other
applications requiring low power consumption. These 2.4 GHz
OEM modules come in 1 mW (ZMN2405/ZMN2430) transmit
power versions for short-range applications and in 10/100 mW
(ZMN2405HP/ZMN2430HP) versions for applications needing
extended range or high resistance to multipath fading. Zigbee
mesh networking makes these modules well suited to industrial
and factory environments.
RFM ZigBee modules can be installed like integrated
Product No.
ZMN2405HPDK-B
ZMN2405HPDK
ZMN2405HPDKPro
ZMN2405DK
ZMN2405DKPro
Description
Basic development kit for the ZMN2405HP/ZMN2430HP module including one
RS-232 serial modem, one development board, demonstration software, power
supplies, antennas, and batteries
Development kit for the ZMN2405HP/ZMN2430HP module including two development
boards, demonstration software, power supplies, antennas and batteries
Development kit for the ZMN2405HP/ZMN2430HP module with four remote boards
and one serial gateway board, demonstration software, power supplies, antennas
and batteries
Development kit for the ZMN2405/ZMN2430 module including two development
boards, demonstration software, power supplies, antennas and batteries
Development kit for the ZMN2405/ZMN2430 module with four remote boards and one
serial gateway board, demonstration software, power supplies, antennas and batteries
ZigBee Gateways
circuits. Even though they are complete OEM modules, they
are reflow soldered to the host PCBs—there is no need for
Product No.
ZG-2400E Ethernet Gateway
Frequency
2.400-2.4835
Transmit Power
10/100 mW
Channels
15
Data Rate
250 Kbps
expensive, unreliable connectors. With its small footprint, there
is no size penalty associated with the convenience of a
module. RFM has relied on its experience in helping hundreds
of OEMs integrate RFM modules to create a full set of
development and configuration tools.
Denotes New Product
* Release date pending. Check for availability.
?
?
?
?
?
Ad hoc mesh network — Redundant, self-forming,
self-healing network
Low cost — Extends wireless to virtually any sensor
Low power consumption — Ideal for battery operation
Small size, light weight — Easy to integrate
Direct sequence spread spectrum — Fast acquisition
time
25
